6′x12′ 10K Tandem Axle Open Utility Suncoast Trailer
Available Colors for Body:
- Custom: Color/Wrap
Available Options
- Torsion Axles
- Side W/ Mesh -or- Solid Steel
- Electric Brakes
- Tailgate Ramp, Spring Assist
- Deck: 1/8” Steel Diamond Plate
- Tailgate Ramp, Length 54”, 60”, 66”, 72”
- Flatbed or Side Rails
- Tailgate Ramp, Optional Removable
- Side Rails with 1.25” Tubular
- Equipment Options: Welded for Security
- Side Rails Heights: 12”, 16”, 24”, 48”
- Hitch Utility Box and OPE Equipment Holders
CAPACITY
- SKU:SCU6X12K10
- GVWR: (AXLE WEIGHT CAPACITY)9,900 lbs.
- Size:Width 6′ X Length 12′
- Suspension Type:Spring Axle W/ Torsion Option
CONSTRUCTION
- FRAME:(HD Tube)-1"x1" 18G, 2"x1" 16G, 4"x2" 11G, 2”X1/2” Angle Cross Member
- Interior Walls/Floor:(Plywood) 3/8" Walls, 5/8" Ramp, (Plank) 2"x8"
- Exterior Sides:(Aluminum) .032 White, .040 Colors
- Axle Type:Tandem 3.5K Torsion W/ E.Brake
- TONGUE:4" Channel (Optional 5" SHD)
- COUPLER:2" Steel Coupler (2-5/16" Availabe on 5K-14K Series)
- JACK:2,000 lbs. -or- 7,000 lbs. Rated Screw Jack
- TIRES:205/75 R15
- WHEELS:White -or- Black
