OPEN UTILITY TRAILERS

8’x20’ 10K Tandem Axle Open Utility Suncoast Trailer

Available Colors for Body:

Custom: Color/Wrap

Available Options

Torsion Axles
Side W/ Mesh -or- Solid Steel
Electric Brakes
Tailgate Ramp, Spring Assist
Deck: 1/8” Steel Diamond Plate
Tailgate Ramp, Length 54”, 60”, 66”, 72”
Flatbed or Side Rails
Tailgate Ramp, Optional Removable
Side Rails with 1.25” Tubular
Equipment Options: Welded for Security
Side Rails Heights: 12”, 16”, 24”, 48”
Hitch Utility Box and OPE Equipment Holders

CONFIGURE AND ORDER NOW

Skip to the end of the images gallery

main product photo

Skip to the beginning of the images gallery

CAPACITY

SKU:SCU8X20K10
GVWR: (AXLE WEIGHT CAPACITY)9,900 lbs.
Size:Width 8′ X Length 20′
Suspension Type:Spring Axle W/ Torsion Option

CONSTRUCTION

FRAME:(HD Tube)-1"x1" 18G, 2"x1" 16G, 4"x2" 11G, 2”X1/2” Angle Cross Member
Interior Walls/Floor:(Plywood) 3/8" Walls, 5/8" Ramp, (Plank) 2"x8"
Exterior Sides:(Aluminum) .032 White, .040 Colors
Axle Type:Tandem 3.5K Torsion W/ E.Brake
TONGUE:4" Channel (Optional 5" SHD)
COUPLER:2" Steel Coupler (2-5/16" Availabe on 5K-14K Series)
JACK:2,000 lbs. -or- 7,000 lbs. Rated Screw Jack
TIRES:205/75 R15
WHEELS:White -or- Black
